Galvanized Type Of C Purlin Cold Rool Forming Machine / C Z U Purlin Roll Forming Machine In China
The specs of C Z U purlin cold roll forming machine could be customized according to your detail requirements.We promise to provide high quality machines with best price. The machine is widely used in villa,plant and house building.It is simple and strong and popular with many builders.
Manual decoiler | 1).Material coil inner diameter: 450mm-550mm 2).Max coil width:300mm 3).Carrying capacity: 1.5T |
| Forming device | 1)Shaft material:high grade No.45 steel after treatment 2) Out diameter: 50 mm 3)Roller material: Cr12 polished and coated with chrome HRC55-60° 4)Forming speed:30m/min 5)Main motor power:5.5 kw 6)Roller station:10-12stations 7)Voltage:380v,50Hz,3 phase 8)Main frame structure: memorial arch structure 9)Control device:automatic cumputer control ,by PLC,operate easily 10)Cutting device: hydraulic tracking cutting(you can also request to add a servomotor,the production speed can be reached 40-60m/min) 11)Transmission: gear drive |
| Hydraulic cutter | 1). material of blade: Cr12 mould steel with quenched treatment 55-60°C 2). cutting system: adopt advanced hydraulic drive, after forming automatic cut, no distort, no wasting , high safe factor.(main motor stop cutting) |
| Control system | Type: PLC Frequency Control System with touch screen Length Error: ±2mm (about the electrical apparatus element ,customers also can specify the brand) |
| Outpur table | It is simple and used to load finished product. Length:6m |
Features & Purposes:
Z-type steel machine strengthens its firmness with an arch type, stabilizes its operation
with gearbox drive, and improves product quality by adopting molding shearing to avoid
port deformations.Products are widely applied in purline set-up of steel-structure houses.
Profile, layout & production flow:
Steel thickness (t): from 1,5 mm to (at least) 3,0 mm;
Profile height (A): as following list
Flange width (B): as following list
Lip width (C): as following list
Minimum finished product length: at least 500 mm;
Maximum finished product length: at least 12000 mm;
Length tolerance: ±1.5mm per each pieces
Coiler loading → feeding-in with guiding (metal sheet is guided into the first forming station) → straighten → rolling & forming → hydraulic cutting → stacker running out
FAQ
Q:What’s the delivery time?
A:Normaly will take 60days, for small lines will take 30 days.
Q:Do you have after-sale support?
A:Yes, we’re always here for giving you advice and support for technical details since we have senior technician. Our 24-in-service number is +86-18951563725
Q:Is there quality control when manufacturing the lines?
A:Yes, we have a group of team who will be responsible for quality control from laying off the raw material, processing the rollers and the other parts, make treatment on the roller surface and shaft, assembling, testing and packaging.
Q:What’s your strength comparing to the other supplier?
A:We’ll supplying you the best quality and service. We’ll give you good advise beyond your requirements. The lines are easily for installation and with low mantenance requirements.
Q:Can we be your agency abroad?
A:Surely if you have business for roll forming lines and we will welcome a lot for cooperating together.
Our Services
Purlin use automatic metal steel track c u shaped steel roll forming machine
1. Our gurantee pieod is 12month after shipping the line.
2. We will send engineer abroad if the customer required for training and installation.
3. We'll here for replying you for 24hours, our service number is +86-18951563725
Machine Picture:
Packing & Delivery
